Horizontal Form Fill Seal Machine

Request a Quote

Horizontal Form Fill & Seal Machines

The PACKITEC HFFS pouch machine creates pouches from a roll of packaging material, fills them with a product (such as liquid, powder, grains, Solid, Paste, Tablets, etc.), and seals the pouches.

We have HFFS mechanical CAM-operated machines as well as H3 NEXT series, which is a complete full servo series.

Customization is possible in machine construction, filling system, and pouch forming sequence according to customer application, pouch style, product to be filled, working environment, and different industries.

Compatible with different filling systems:

  • Multi-Head Weigher Linear Weigher
  • Auger Powder Filler
  • Liquid / Paste Filler

Pouches can be created in an HFFS machine:

Plain & Stand Up pouch with or without a Zipper

and a Hanging hole, Plain and stand-up pouch with

Corner or Center Spout.

Machine Features

1. PLC control operating system makes for easy and simple maintenance.
2. The machine has with automatic film align and adjust device.
3. A versatile machine could make a variety of pouches according to requirements.
4. Independent digital temp. controller for vertical and horizontal sealing, intuitive and accurate.
5. Easy & fast adjustment of changeover, the machine has strength and extensibility, and could fill two Or even more products into one bag by adding a filling device.
6. Smooth performance and low noise, perfect package appearance, sensible safety device, and no pollution during production to get a friendly working environment
7. Motion control syncs speeds of film unwinding, pulling, and filling with the main machine, adjustable via touchscreen, saving film & time.
8. Advanced photoelectric sensor tracking system and servo motor pull for precise bag width and position of the film.

Technical Specifications

Model: H3-240

  • Pouch Size: 100*120mm(Min), 240*320mm(Max)
  • Filling Method: Liquid filler/auger filler/weigher
  • Filling Capacity: Depend on the filling system
  • Packing Capacity: 30-50ppm, For mechanical cam model
  • Power Consumption: 12 kW
  • Power Specification: 415V, 50Hz
  • Air Consumption: 400NL/min
  • Machine Dimensions: 8500mm(L), 1250mm (W), 1550mm (H)
  • Weight Approx: 2900kg

Application:

Used in various industries. Such as Food & Beverage,

Pharmaceutical, Pet food, Snacks food,

Confectionery, Chemical, Frozen food and Many others.

Model: H3-330

  • Pouch Size: 150*200mm(Min), 330*450mm(Max)
  • Filling Method: Liquid filler/auger filler/weigher
  • Filling Capacity: Depend on the filling system
  • Packing Capacity: 30-40ppm, For mechanical cam model
  • Power Consumption: 14 kW
    Power Specification: 415V, 50Hz
    Air Consumption: 500NL/min
  • Machine Dimensions: 8800mm(L), 1200mm (W), 1500mm (H)
  • Weight Approx: 3500kg
